WSV
Wood Flooring Screw
The WSV is the new improved subfloor screw from Simpson Strong-Tie. The subfloor screws have been re-engineered to reduce driving force and increase installation speed. Less installation torque means reduced wear on tools. WSV screws have a sharp point with an aggressive variable thread resulting in faster, smoother installations. The deep T25 6-lobe recess provides improved control and greater bit life whilst the ribbed head design countersinks easily providing a clean, flush finish.

CE Marking

New

Service class 2
EPD

Yellow electro-galvanised steel

Indoor
WSV_SSTBP_homepage_DK_da
Product Details
Features
Material
- Steel - electro galvanised coating
Features
- CE marked to EN14592
- Sharp point with aggressive variable thread
- Bit (TX25) included
- Ribbed, countersunk head
Application
Header member
- Wood to wood applications
Common Applications
- Wood to wood applications
- Subfloor installation
Technical Data
Dimensions
| Reference | Fasteners Dimensions | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Other | Product Dimensions[mm] | QD information | |||||||||
| Tun / DB nr. | NOB nr. | Qty per Box | Weight[kg] | Total Length[mm] | Thread Diameter[mm] | Head diameter[mm] | lg[mm] | Qty per Strip | Recommended RPM[U/Min.] | Quik Drive Attachment | |
| WSV44E | 2135433 | 57302193 | 2000.0 | 0.004 | 44 | 4.6 | 8.5 | 31 | 30.0 | 2500-4500 | QDPRO64E / QDPRO76SKE |
| WSV51E | 2135437 | 57302204 | 2000.0 | 0.004 | 51 | 4.6 | 8.5 | 37 | 30.0 | 2500-4500 | QDPRO64E / QDPRO76SKE |
| WSV64E | 2135439 | 57302212 | 1500.0 | 0.005 | 64 | 4.6 | 8.5 | 50 | 30.0 | 2500 | QDPRO64E / QDPRO76SKE |
| WSV76E | 2135440 | - | 1000.0 | - | 76 | 4.6 | 8.5 | 55 | 30.0 | 2500 | QDPRO76SKE / QD76KE |
Structural parameters - EN14592
| Reference | Screw Parameters | |||||
|---|---|---|---|---|---|---|
| Characteristic parameters | ||||||
| Characteristic moment of elasticity - My,ₖ[Nm] | Characteristic pullout parameter[N/mm²] | Characteristic head traversal parameter[N/mm²] | Characteristic pulling capacity[kN] | Characteristic resistance to torsion - Rₜₒᵣ,ₖ[Nm] | Torsional ratio | |
| WSV44E | 3.5 | 14.7 | 31.3 | 8.2 | 5.9 | ≥ 1,5 |
| WSV51E | 3.5 | 14.7 | 31.3 | 8.2 | 5.9 | ≥ 1,5 |
| WSV64E | 3.5 | 14.7 | 31.3 | 8.2 | 5.9 | ≥ 1,5 |
| WSV76E | 3.5 | 14.7 | 31.3 | 8.2 | 5.9 | ≥ 1,5 |
Panel to Timber Characteristic Capacities
| Reference | Screw Loads | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Product characteristic capacities - Panel (OSB, Fibreboard ρk≥380 kg/m3) on Timber C24 depending on panel thickness tp | |||||||||||||||
| 13 mm[mm] | 15 mm[mm] | 22 mm[mm] | 18 mm[mm] | 25 mm[mm] | |||||||||||
| Rax.k.13[kN] | Rv.0.k.13[kN] | Rv.90.k.13[kN] | Rax.k.15[kN] | Rv.0.k.15[kN] | Rv.90.k.15[kN] | Rax.k.22[kN] | Rv.0.k.22[kN] | Rv.90.k.22[kN] | Rax.k.18[kN] | Rv.0.k.18[kN] | Rv.90.k.18[kN] | Rax.k.25[kN] | Rv.0.k.25[kN] | Rv.90.k.25[kN] | |
| WSV44E | 2.03 | 1.27 | 1.27 | - | 0.83 | 0.83 | - | 0.93 | 0.93 | - | 0.93 | 0.93 | - | 0.85 | 0.85 |
| WSV51E | 2.42 | 1.37 | 1.37 | 2.42 | 1.43 | 1.43 | - | 1 | 1 | 2.23 | 1.49 | 1.49 | - | 1.01 | 1.01 |
| WSV64E | 2.42 | 1.37 | 1.37 | 2.42 | 1.43 | 1.43 | 2.42 | 1.61 | 1.61 | 2.42 | 1.53 | 1.53 | - | 1.01 | 1.01 |
| WSV76E | 2.42 | 1.37 | 1.37 | 2.42 | 1.43 | 1.43 | 2.42 | 1.61 | 1.61 | 2.42 | 1.53 | 1.53 | 2.42 | 1.61 | 1.61 |
Plywood to Timber Characteristic Capacities
| Reference | Screw Loads | |||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Product characteristic capacities - Plywood (ρk≥490 kg/m3) on Timber C24 depending on panel thickness tp | ||||||||||||||||||
| 10 mm[mm] | 15 mm[mm] | 18 mm[mm] | 22 mm[mm] | 25 mm[mm] | 30 mm[mm] | |||||||||||||
| Rax.k.10[kN] | Rv.0.k.10[kN] | Rv.90.k.10[kN] | Rax.k.15[kN] | Rv.0.k.15[kN] | Rv.90.k.15[kN] | Rax.k.18[kN] | Rv.0.k.18[kN] | Rv.90.k.18[kN] | Rax.k.22[kN] | Rv.0.k.22[kN] | Rv.90.k.22[kN] | Rax.k.25[kN] | Rv.0.k.25[kN] | Rv.90.k.25[kN] | Rax.k.30[kN] | Rv.0.k.30[kN] | Rv.90.k.30[kN] | |
| WSV44E | 2.03 | 1.22 | 1.22 | - | 0.84 | 0.84 | - | 0.94 | 0.94 | - | 0.93 | 0.93 | - | 0.85 | 0.85 | - | - | - |
| WSV51E | 2.5 | 1.27 | 1.27 | - | 0.84 | 0.84 | - | 0.94 | 0.94 | - | 1 | 1 | - | 1 | 1 | - | 0.9 | 0.9 |
| WSV64E | 2.96 | 1.27 | 1.27 | 2.96 | 1.58 | 1.58 | 2.96 | 1.68 | 1.68 | - | 1 | 1 | - | 1 | 1 | - | 1 | 1 |
| WSV76E | 2.96 | 1.27 | 1.27 | 2.96 | 1.58 | 1.58 | 2.96 | 1.68 | 1.68 | 2.96 | 1.74 | 1.74 | 2.96 | 1.74 | 1.74 | 2.96 | 1.74 | 1.74 |
Certification
Environmental Product Declarations (EPD)
CAD and BIM Library
2D
WSV64E
-
-
-
-
WSV44E
-
-
-
-
WSV76E
-
-
-
-
3D
WSV64E
-
-
-
-
-
WSV44E
-
-
-
-
-
WSV76E
-
-
-
-
-
